SKF Withdrawal sleeves AOHX 32/500G

SKF Withdrawal sleeves can be used to mount bearings with a tapered bore onto the cylindrical seat of stepped shafts (fig. 1). The sleeve is pressed into the bore of the bearing inner ring, which abuts a shaft shoulder or similar fixed component. The sleeve is located on the shaft by a nut or an end plate. KM or HM lock nuts (Lock nuts requiring a keyway) with appropriate locking devices are suitable. Lock nuts are not supplied with the sleeve and must be ordered separately. End plates are not manufactured by SKF.

Get A Quote
Contact Us

SKF Withdrawal sleeves.

Various part numbers in stock, welcome inquiry. Fast shipment within 2-3 working days.



Designation Principal dimensions Associated products
Hydraulic nut Nut for removal
d1[mm] d[mm] B1[mm] B2[mm]
 AOH 3272G   340   360   274   283   HMV 76E   HM 3176
 AOH 3276G   360   380   284   294   HMV 80E   HM 3180
 AOH 3280G   380   400   302   312   HMV 84E   HM 3184
 AOH 3284G   400   420   321   331   HMV 88E   HM 3188
 AOHX 240/600   570   600   310   336   HMV 126E   HM 31/630
 AOHX 241/600   570   600   413   439   HMV 126E   HM 31/630
 AOHX 30/500G   480   500   209   221   HMV 106E   HM 30/530
 AOHX 30/560   530   560   240   252   HMV 120E   HM 30/600
 AOHX 30/600   570   600   245   259   HMV 126E   HM 30/630
 AOHX 30/710   670   710   286   302   HMV 150E   HM 30/750
 AOHX 3088G   420   440   194   205   HMV 92E   HM 3092
 AOHX 3092G   440   460   202   213   HMV 96E   HM 3096
 AOHX 3096G   460   480   205   217   HMV 100E   HM 30/500
 AOHX 31/500G   480   500   313   325   HMV 106E   HM 31/530
 AOHX 31/600   570   600   355   369   HMV 126E   HM 31/630
 AOHX 31/670   630   670   395   409   HMV 142E   HM 31/710
 AOHX 31/710   670   710   405   421   HMV 150E   HM 31/750
 AOHX 3188G   420   440   270   281   HMV 92E   HM 3192
 AOHX 3192G   440   460   285   296   HMV 96E   HM 3196
 AOHX 3196G   460   480   295   307   HMV 100E   HM 31/500
 AOHX 32/500G   480   500   393   405   HMV 106E   HM 31/530
 AOHX 3288G   420   440   330   341   HMV 92E   HM 3192
 AOHX 3292G   440   460   349   360   HMV 96E   HM 3196
 AOHX 3296G   460   480   364   376   HMV 100E   HM 31/500
